How Do MIG Welders Work?

Basics of MIG welding and all you need to know

MIG welding is an arc welding process that utilizes a continuous solid wire that is heated and fed into a weld pool from a welding gun. This causes the two base materials to melt together and form a joint, which is the process’s goal. MIG stands for metal inert gas, and the method of welding is described as so because the welding gun that feeds the solid wire electrode also feeds a shielding gas along with the electrode. This gas is to help protect the weld pool from unwanted airborne contaminants.

The process was first patented in the United States in the late 1940s for utilization in aluminum welding. 1 Trusted Source Gas metal arc welding - Wikipedia Gas metal arc welding (GMAW), sometimes referred to by its subtypes metal inert gas (MIG) and metal active gas (MAG) is a welding process in which an electric arc forms between a consumable MIG wire electrode and the workpiece metal(s), which heats the workpiece metal(s), causing them to fuse (melt and join). en.m.wikipedia.org  Back then, the arc and the weld pool formed were protected by helium which was the first inert gas used as a shielding gas. Over time, though, argon also became very popular as a shielding gas, but CO2 was used as a shielding gas in the welding of carbon steel. However, due to the nature of CO2, any time CO2 or a CO2-argon mixture is used as a shielding gas, the process is referred to as metal active gas (MAG) processes instead.

The MIG welding makes use of an arc at the tip of the wire electrode. During the welding process, the wire electrode acts as both a heat source and a source of the welding joint’s filler metal. The arc located at the tip of the wire is required to melt along with the workpiece to create the weld pool.

The electrode itself is fed welding current via a copper contact tube. The weld pool is created as a result of the melting together of the arc, and the workpiece is protected by the shielding gas supplied through a nozzle surrounding the wire. The nature of the shielding gas depends on the type of metal being welded and the reason for the welding, but regardless, the function is the same; to protect the weld pool from contamination.

During the process, the wire used is continuously fed from a reel or spool powered by a motor drive. Continuous feeding is one of the reasons for the relatively high productivity of the process. The wire used may be solid or cored. While the solid wires are just simple drawn wires, the cored wires are composites made up of metal sheaths that may contain either powdered flux or metal filling within them.

Before you start using a MIG welder, you should know that the procedure’s operating features would be determined to a great extent by the mode of delivery of the metal from the electrode to the weld pool. The three major delivery modes are the droplet or spray, the dip or short-circuiting, and the transfer’s pulsed modes.

The short-circuiting mode of metal transfer is used to transfer the metal by dipping it into the weld pool. When using this method, care has to be taken to set the voltage and inductance right relative to the wire feed speed to minimize the molten metal’s spatter. The inductance, primarily, is also used to negate surges in current that may occur when the wire electrode dips into the weld pool.

The pulsed delivery method was developed to avoid short-circuiting and spatter by stabilizing the arc at low currents. The transfer of the metal is affected by the release of pulses, each possessing sufficient force to release a droplet of the molten metal at a time. This mode of metal transfer led to the development of the synergic pulsed MIG, which refers to a type of controller that enables the power source to be tuned for the wire composition and size while ensuring that the pulse frequency is in sync with the wire feed speed.

The droplet transfer uses a higher voltage to ensure that the wire electrode doesn’t make contact with the weld pool. Instead, the molten metal at the tip f the wire is transferred to the weld pool as small droplets or a spray. However, it should be noted that there is a minimum current level below which the molten metal would no longer be forcibly ejected as a spray but would instead form large droplets which would fall under normal gravitational forces and lead to spatter.

It should be clear that the short-circuiting and pulsed methods of metal transfer or delivery are utilized for low current operations, while the spray method is used with high welding currents.

In addition to protecting the weld pool from contaminants, the shielding gas also plays a role in the stability of the arc, the weld pool’s behavior, and the transfer of metal from the wire to the weld pool. Specifically, the shielding gas stabilizes the arc’s roots on the workpiece’s surface, ensures the smooth transfer of droplets to the weld pool, and forms the arc plasma.

Many gases can be used as shielding gases, but the specific gas used depends on the employed process and the type of material the welder is working with.

General-purpose gases for MIG welding processes are mixtures of argon, oxygen, and CO2, although special gas mixtures may contain helium.

However, based on the nature of the metal being welded, the gas or mixture of gases used can be varied as thus:

• For steels, specific gases used are CO2, a mixture of argon and 2-5% oxygen, or a mixture of argon and 5-25% CO2.
• Non-ferrous metals such as aluminum, copper, and nickel alloys require argon or an argon-helium mixture.
• Having spoken about the ease with which a MIG welding machine can be used and the function of the various parts of the machine, it is essential to point out that regardless of how confident you are of your ability to master the machine, specific steps must be taken before you start welding any metals.

Some of these steps are:

1. Before you begin welding, get yourself the appropriate safety gear and apparel for protection. Such gear includes safety glasses to protect your eyes, a welding helmet to protect the head during welding, leather gloves to protect your hands from sparks and spatter, flame-resistant long sleeve jackets to protect the body and leather boots. An excellent example of professional welders’ right protective gear is the Jackson Safety Helmet, which is lightweight enough to be comfortable while being protective.

2. Any source of a potential fire breakout should be cleared from the welding site or workshop. This is to prevent the sparks that would be produced during welding from becoming more hazardous.
3. Keep a fire extinguisher close by just in case.

If the above steps have been taking to ensure your safety during welding, you must also ensure that your working area and equipment are in the right state to produce the best quality work. Such preparatory actions should not be limited to only the equipment, though. Emphasis should be placed on the workpiece to be welded also.

For instance, use a metal brush to clean the metal’s surface to get rid of contamination and ensure that when clamping your work metal down, no impedance present might affect the wire feed.

Once the metal is cleaned, a similar level of attention should be paid to the welding machine itself. Before using the machine, always check all cable connections and ensure that they are tight and free of damage. You could also check for leaks in the shielding gases’ supply as this could raise the cost associated with the use of your welding machine while leaving you with less protection against contamination.

Another common problem you might encounter during welding is too much or too little tension on the spool feeding the wire. You should, therefore, check this before you start welding to avoid any unnecessary stoppages once the real work is underway.

Lastly is the maintenance of the machine. Regularly clean the machine to remove any spatter that might be there, replace worn contact tubes, and replace rusty wires.

Advantages and disadvantages of MIG welding

The MIG welding operation is widely used and accounts for a large portion of all weld metal deposited. This widespread use can be attributed to the fact that the MIG welding process is more versatile than the MMA, is more suitable for mechanization than the MMA, and has relatively higher deposition rates. It should, however, be noted that MIG welding requires a higher degree of skill on the part of the welder than the MMA does.

The MIG welding machine’s popularity as the go-to machine for professionals and beginners alike should be enough proof that it has numerous advantages. But there’s nothing like specifics to make the message stick.

1. MIG welding machines offer relatively higher productivities than any other type of welding machine on the market. The choice of whether or not to make it run automatically, semi-automatically or in a mechanized state is also a massive plus among potential customers. Being able to work faster without the need to adjust or clean continually is very attractive, indeed.

2. MIG welding is more comfortable to learn compared to alternatives. People may go as far as calling MIG welding a point-and-shoot process, and they wouldn’t be far from the truth. However, it has a few intricacies that you need to be conscious of if you have the welding machine performing optimally for you, but these details are still more straightforward to comprehend than those of, say, TIG welding.
3. MIG welding allows for a clean and efficient job. Thanks to the shielding gases employed in the process, there is little to no contamination of the weld pool. Due to the efficient modes of metal transfer utilized by MIG machines, there is minimal spatter to clean up after a project is completed.
4. The versatility of MIG welding is also a big plus. As earlier stated, the machine can be used in various ways and on different metals and alloys. It can be used for materials of varying thicknesses and minor variations being made to the welding machine.

Like all things in life, MIG welding is not perfect. Just as it has advantages, it also possesses disadvantages. Most people would argue that the benefits more than make the burdens bearable, but the following penalties should be taken into consideration:

1. The welding machine might not be suitable for outdoor work. Since the device utilizes gas to provide a shielding effect, wind and general outdoor conditions might interact with the gases’ ability to function correctly. Consequently, this would negate the MIG welder’s vital advantage, which is its ability to produce a relatively clean weld and minimize spatter.

2. Because shielding gases protect the purity of the weld and prevent slag formation, there might be a noticeable increase in cooling rate when MIG welding is being utilized. This might not have much of a negative effect, though, as the heat of the process is supplied from the wire electrode and adjusted.
3. MIG welding machines are easy to use and help quickly complete a project, but those advantages come at a higher price. However, the initial cost of purchase of the machine is not the only one to consider as overtime, changing wire electrodes, nozzle tips, and purchasing gas might start to take a financial toll on your bank balance.

Tips for beginners

If you are a beginner and are planning to take up welding as a hobby or you want to add a new skill to make you as handy as possible, here are some tips to keep in mind that may make your learning more straightforward, with emphasis placed on things you might find difficult:

1. The position in which you are welding should factor into how you handle the welding gun. For instance, if you are welding overhead, you must lower the machine’s voltage and amperage. This, combined with the use of a wire that is small in diameter, would help to reduce the weld puddle. Also, it would help if you moved the welding gun quickly to ensure that the weld metal doesn’t fall out of the joint before you are done.

2. When you are welding thin metals or metal sheets in a vertical position, you might find it more helpful to weld vertically down to avoid melting through the metal. In this case, you begin at the top and work your way down, keeping the wire away from the weld pool. However, if you are dealing with thicker metals, it would be better to weld vertically up with the welding starting from the joint’s bottom.
3. Be sure to set the amperage and voltage as is appropriate for the work you are doing. Most MIG welding machines make this easier by allowing you to select the diameter of the wire you’d be using and the thickness of the metal you’d be welding. This, in turn, allows the machine to automatically adjust the voltage, amperage, and wire feed speed to suit your project.

Some factors to consider when buying a MIG welder

Naturally, welding machines are quite expensive, and the versatility and ease with which a MIG welding machine can be operated make it even more costly than most. Along with the fact that not all MIG welding machines are suitable for all jobs, this makes having the right information and orientation necessary when purchasing a welding machine.

Not to worry, though; we got you covered with factors to consider when purchasing a MIG welding machine that provides the best value for the cost that you can get.

• Your budget – It is okay to want the best, but the best is always more expensive than the rest, and the same applies to MIG welding machines. To ensure that you truly get your money’s worth in the purchase, why not outline what you may need the welder and then decide what features you would prefer. You would be shocked to find out just how much such critical thinking might save you.
• The voltage on the MIG – The MIG’s value to you as a hobbyist tool or a handyman’s solution depends on its function. If you need the welder to perform dome simple workshop repairs, you might not necessarily need to purchase the most powerful welder in the store, so 110v MIG welders will do just fine. Compromising according to value and power won’t just save you money on the initial purchase but might also save you a few dollars on your energy bills.
• Size – The size and weight of the MIG are also a significant determinant of its cost. There are portable MIG welding machines that can be carried easily and are more convenient to use. You could even invest in a longer cord to make it more comfortable if you might need to work a bit far from a power outlet. However, if you settle on a heavier one, for whatever reason, add the cost of a wheeling cart for both the welder and the tank for its shielding gas to your budget.
• Check out the brands – There’s always going to be some cheap brand trying to hawk cheap MIG welders, but rather than jumping at a low price, try checking out brand reputations and reviews before making a financial decision on which brand would work best for you.

Final thoughts

Before reading this, you might have been considering hiring a professional to help you with that new joint you need to weld, but this sounds just too interesting for you not to try it.

We hole this article helped you figure out how MIG welders work. All that’s left to do is to purchase the welder most suitable to your needs and get started with making the sparks fly!
